specific purposes: dry glassware, experimental samples, food, chemical heat denaturation, hot rigid, heat softening, moisture elimination, biological engineering utensils, appliances dry hot sterilization, electronic components drying, aging.
model
MG-9030A
MG-9070A
MG-9140A
MG-9240A
work environment
Ambient temperature ranged from 5 to 30℃
Relative humidity of 80%
The altitude is 2000m
Power supply AC220V± 10% 50Hz ± 1Hz
control range
Room temperature ranged from + 10℃ to 200℃
temperature
resolution ratio
0.1℃
fluctuation
±0.5℃
controller
LCD display, push-button, fuzzy PID control technology of microprocessor temperature control
sensor
High-precision platinum resistance sensor
time
0~9999 minutes
consumed power
650W
850W
1450W
2000W
capacity
30L
70L
140L
240L
material
interior
304 mirror-surface stainless steel
outside
08F cold-rolled steel plate
size
(MM)
interior
340*320*320
450*400*450
550*450*550
600*500*750
outside
620*530*490
740*618*630
840*670*730
880*720*930
Product features:
1. Desktop, back heating type, horizontal forced convection, imported fan, inlet and outlet air volume can be adjusted to ensure the uniform temperature of the studio.
2. Choose a high-performance CPU processing chip and a platinum resistance sensor temperature control system to make the temperature control accurate and easy to operate.
3. With sensor fault alarm, overtemperature alarm, self-diagnosis dynamic control, temperature display correction, parameter memory and timing function of up to 9999 minutes.
4. The optional independent temperature limit control system will automatically interrupt the work after the fixed temperature.(apolegamy)
